USB FeedThrough connectors saves space on control panels and reduces component count

04-06-2025 | Cliff Electronics | Power

Cliff Electronics has extended its FT Connector range with the addition of dual USB 2.0, USB 3.0 and USB-C metal FeedThrough Connectors. The new dual-connector design saves panel space and reduces component count. They are simple to integrate into control panels, as both sides use standard USB cables, which simplifies the assembly process and makes it easier to service or repurpose.

The connectors are available in durable silver-finished metal or black metal finishes and are suitable for a wide variety of applications, including automotive connectivity, consumer electronics, smart home devices, medical equipment, audio/broadcast systems, charging stations, and power banks.

The introduction of these dual USB passthrough keystone couplers helps streamline the setup of modern devices, offering convenience and flexibility for both data and power needs.

The company's feedthrough connectors are designed to be assembled into an industry-standard, 24mm diameter XLR connector panel cutout in an enclosure or 19" rack panel. Using industry-standard panel cutouts simplifies system design and assembly while also improving system aesthetics. Pre-assembled rack panels are available on request.

Key features of these connectors include:

  • Higher connectivity in the same panel space with two USB ports in the same industry-standard XLR panel cutout (24mm). Space saving is now a key driver in rack and enclosure design.
  • Simplified Cabling with a reduction in the number of required panel cutouts and mounting hardware. Less machining reduces manufacturing costs, and a reduced number of cables through the panel improves reliability and aesthetics.
  • Cost efficiency is achieved by reducing the number of components required and leveraging economies of scale in component purchasing and assembly.
  • Cleaner and more professional installations are achieved by using a single symmetrical dual-port mount, which reduces panel clutter and simplifies labelling. Important in customer-facing or high-visibility equipment (e.g., AV, broadcast, live events).
  • Fewer Points of failure result from fewer mechanical mountings, decreasing the chance of loose or misaligned connectors and improving mechanical durability and long-term reliability.

The company's growing range of FeedThrough connectors now provides analogue, digital and optical connectivity in formats including BNC (50Ω or 75Ω), DisplayPort, HDMI, Optical fibre (FC, LC Duplex, SC Simplex, ST BFOC, TOSLINK and US Conec MTP brand MPO), RCA phono, RJ45 ethernet (UTP or FTP) in Cat6, Cat6a or Cat5e, USB 2, USB 3 and USB-C.
