Common-mode chip inductors minimise noise intrusion

18-11-2022 | Mouser Electronics | Passives

Eaton ACE2V3225 Common-mode Chip Inductors, available now from Mouser, are AEC-Q200 qualified automotive-grade chip inductors with OPEN Alliance 2.0 compliance. These chip inductors offer exceptional filtering with low parasitic capacitance to minimise noise intrusion in data lines on CAN and Ethernet vehicle connectivity modules.

The chip inductors provide a common-mode inductance range from 80µH to 200µH and 3000-Ohm to 9500-Ohm common-mode impedance range. These common-mode chip inductors operate within the -40C to 125C temperature range and are available in 1210 (3225 metric) packages.

Typical applications include Ethernet architectures, ADAS, infotainment, safety cameras, sensors, powertrains, and EVs.

By Seb Springall
