Affordable new arbitrary / function generator for education and entry-level T&M

02-04-2015 | Tektronix | Test & Measurement

Tektronix has introduced the AFG1022 - an entry level arbitrary / function generator featuring best-in-class performance and functionality to support a wide range of use cases and course subjects. The AFG1022 integrates seamlessly with the new TekSmartLab wireless lab instrument management solution.

As electronic systems continue to increase in speed and complexity, colleges and universities globally are looking to outfit labs with modern test instrumentation to better prepare students for the real world. With the addition of the AFG1022, Tektronix now offers educational institutions the industry’s most complete set of affordable instruments including oscilloscopes, signal generators, digital multi-meters and power supplies, all tied together with TekSmartLab, says the company.

“Tektronix strongly believes that a rich hands-on experience dramatically improves education outcomes,” said Michael Ewald, general manager, bench products, Tektronix. “That’s why we are working hard to meet the needs of colleges and universities including superior price-performance on instrumentation, integrated courseware and ease of administration. We are the one-stop-shop for basic education test solutions.”

Compared to scope-based signal generators or stand-alone AFGs in its price class, the AFG1022 offers better performance and greater flexibility. Key performance specifications include dual-channel, 25MHz bandwidth with 1mVpp to 10Vpp output, 14-bit vertical resolution and 1µHz frequency resolution. It provides a 125MS/s sample rate along with 64MB of built-in non-volatile memory and USB memory expansion for user-defined waveforms.

Functionally, the instrument offers 50 built-in standard function and arbitrary waveforms with continuous, modulation, sweep and burst modes to cover almost all the test requirements found in basic education labs. A built-in 200MHz counter with 6-digit resolution offers an easy and precise way of performing frequency, period, pulse width, and duty cycle measurements.

To maximize learning, the AFG1022 incorporates an intuitive user interface with a 3.95-inch TFT colour display, shortcut buttons and rotary knob for quick setting adjustments. Also, its compact form factor saves valuable bench space.
